Structure Features:

1. paper receipt

Ø According to the thickness of the cardboard, the paper inlet is equipped with an spring fine-tuning device to ensure that the cardboard coming out of the printing press can fit perfectly into the folding beam.

2. gluing unit

Ø An independent motor drives the gluing part, and a reducer motor controls the gluing position.

3. Folding unit

Ø The folding unit is driven by a variable frequency motor with variable frequency speed regulation.

Ø The left and right movement of the folding beam is controlled by two reducer motors.

Ø The middle is equipped with a shaping wheel for more accurate folding.

Ø The gantry structure improves the stability of the machine operation.

4. counting ejection unit

Ø The counting ejection unit is driven by variable frequency motor, which has variable frequency speed regulation and is synchronized with the folding unit.

Ø Receiving paper adopts top drop model, then second time counting deisng, Counting is accurate and fast.

Ø Electric carton size adjustment.
