Technical Parameter

Structure Features

Ø Specification of strapping belt: polypropylene, width 5mm, 6mm, thickness 0.5mm～0.8mm; Rolls width: 170mm～190mm; Rolls inner diameter: 200mm～210mm, outer diameter: 400mm～450mm; (10)Option: strapping width 8mm, 9mm, 11mm, 12mm

Ø Japan's latest mechanical structure, free of refueling and maintenance;

Ø Four packing operation modes, manual, continuous play, ball switch, foot switch;

Ø There are three knives, middle knives, front knives, and back knives. The blades are made of gauge steel (manganese 13 material) to ensure the strength and hardness of the knife body, which is more wear-resistant and has a longer life;

Ø The ironing head is made of special stainless steel (copper alloy) material, which is not suitable for aging and deformation.

Ø The T-slot and the slide plate are made of steel, and there is an inverted under the slide plate;

Ø Nitriding is used for the high-wear cassette block;
