Technical Parameter

Structure Features:

1. Max. Speed requirement

Ø Maximum speed requirement:

Ø Paper loading height > 1600mm.

Ø Number of paper stacks per board is within single stack

Ø Cardboard warping requirement: 5% in paper width direction (1000mm, allowable warping within 60mm)

Ø The printed surfaces of the cardboard must be on the same side.

Ø At least one stack cardboard must be kept on the power track at the front end of the paper feeder fork.

2.power features

Ø Number of stacking columns: single column

Ø Cardboard lifting method: hydraulic lifting fork

Ø Turning power: hydraulic drive

Ø Horizontal conveyor bed lifting power: hydraulic drive

Ø Conveyor belt power: hydraulic motor (equipped with independent hydraulic pump station to ensure smooth transportation). Side baffles and front baffles, pneumatic alignment correction, side baffles electric adjustment.

Ø Machine movement: The machine itself can move forward and backward, and the machine automatically moves backward when the printing press is split. Keep the height of the cardboard during work, the lifting fork automatically pushes the cardboard up, and one-button down.

Ø The conveyor belt can automatically control the start and stop of the cardboard according to the height of the paper feeding bin of the printing press.
